Productos relacionados con: GTMEDIA X8
-
Decodificador
-
ESPECIFICACIONES TÉCNICAS
Highlight1.Support DVB-S/S2/S2X, VCM/ACM/multi-stream/T2-MI, HEVC main 10 profile
2.Support BISS auto roll, Full PowerVu, DRE &Biss key;
3.Support Unicable, DiSEqC1.0/1.1/1.2/USALS Motor fully support;
4.Support SAT2IP by GTShare APK, DLNA;
5.Support Built-in 2.4G WIFI module, Ethernet, and support 3G/4G usb dongle;
6.Support Online Movie (Youtube,Youporn,Hotstar);
7.Support IPTV (Customize, xtream, stalker);
8. Support WebTV
9.Technical support website : www.freesat.cn;
Main Chip Sets
CPU
770MHz Dual Core
Flash Memory
64MB SPI Flash
DDR2 Memory
1G bit RAM
TS
Demultiplexer
ISO/IEC 13818-1
Demux
Input Bit Rate
Max 100Mbit/s
Video Decode
Video Decode
HEVC main profile@level 4.1 and main10
profile@L4.1,High tier MPEG-2 MP@ML
H.264 BP,MP&HP@L3/L4.1/L4.2
AVS Jizhun profile and broadcast profile
MPEG-4 SP profile, advanced simple profile@L5 VC1 SP@ML, MP@HL, AP@L0-3
H263 baseline profile
JPEG decoder
TV System
Automatic PAL/NTSC conversion
Aspect Mode
Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box
Video effects
Standard, Default, Vivid.
Video Resolution
1080P, 1080I, 720P, 576P, 480P, 576I, 480I
HDMI Color Space
RGB, YUV422, YUV444, Auto
Audio DecodeMPEG-1/2 Layer 1/2/3, MPEG-2/4 LC-AAC, MPEG-4 HE-
AAC,
Dolby AC3/AC3+, DRA CH/5.1CH
Audio Decode
Sound Mode
LEFT/RIGHT/STEREO/MONO
Sampling Frequen
c32KHz,44.1KHz,48KHz
Audio Out
LPCM Out, BS Out
Hardware specifications
Panel display
4-digit white LED display (Support function display)
LED Indicator
Power ON :Green; Standby :Red
Button
NOT
Wifi
Built in 2.4G WiFi Support IEEE 802.1.1b/g/n
IR
Exit IR for 38KHz,Infra Remote control
Rear Panel
LNB IN (Frequency Range950MHz to 2150MHz)
HD OUT (up to 1080P)
SCART OUT
1*USB HOST
1*RJ45
1*RS232 (3-pin 3.5 mm jack)
DC IN (DC12V/1.5A)
System standard
ETS 302 307
DVB- S/S2
specificati-ons
Frequency Range
950~2150MHz for DVB-S/S2/S2X baseband demodulator
LNB Power and Polarization
DiSEqC1.0/1.1/1.2/USALS Motor fully support, Support Unicable, 13/18V DC @ 400mA MAX, 22KHz±0.4KHz(0.6V±0.2V)tone,Overload Protection
Input Level Range
-80dBm ~ -20dBm (average power)
Symbol Rates
DVB-S QPSK,DVB-S2 QPSK/8PSK/16APSK/32APSK, DVB-S2X QPSK/8PSK/16APSK/32APSK/64APSK
Forward error correction rate
1/4,1/3,2/5,3/5,2/3,3/4,4/5,5/6,8/9,9/10
Carrier frequency acquisition range
±5MHz for symbol rates above 3 Msps and ±3MHz for the remaining symbol rates
Symbol Rates
2 ~ 90MSPS(Code Rate 1/2)
Roll-off factors
Roll-off factors for pulse shaping: 0.2, 0.25 and 0.35
Code Rates
1/2,2/3,3/4,5/6,7/8 for DVB-S, 1/4,1/3,2/5,1/2,3/5,2/3,3/4,5/6
,8/9,9/10 for DVB-S2,
DVB-S2X Normal Frame and Short Frame FEC code rates
ANT. Connector
Connector:IEC TYPE F Input Impedance:75 Ω
StandardFully comply with DVB-S/S2/S2X (SCPC and MCPC
receivable from C/Ku band satellite), MPEG-2/4 and H.265 Standard
Channel Search
Support automatic network search for new added
Channels Number
6000+ channels TV and Radio programmable
ChannelRecording one channel, can view another channel under the same TP,Various channel editing function(favorite,move,lock,skip,delete,rename,find,sort)
Favorites
31 different favorite groups selection
OSD Language
English,French,German,Italian,Spanish,Portuguese,Russian
,Turkish,Polish,Arabic,Persian,Thai,Vietnam,Czech,Armenia n,Georgian,Ukrainian,Albanian,Hungary,Malay,Indonesisch, Dansk,Greek,Serbian.
Sortware
OSD Color
32-bits OSD with anti-flickering
Features
OSD Setting
Support OSD Timeout and Transparency, Subtitle Display, Channel list displays pages 1-3.
Other Setting
Sets up multiple habitual operation Settings
Parental Ctrl
Parental control for channels
Easy Menu
Plug and Play installation, with an easy to use Menu System
EPG
Fully support to 7 days Electronic Program Guide(EPG)
Subtitle
support DVB EN300743 and EBU
Teletext
support DVB ETS300472 by VBI
SoftUpgrade
Software upgrades through USB port, or FTP upgrade.
Time Set
Time set by GMT offset automatic and manual,Summer Time support
Timer
5 event timers,off/Once/Daily/Weekly Mode
USB 2.0
Support FAT/FAT32/NTFS big capacity hard disk
PVR Option
USB 2.0 for PVR,TIMESHIFT,media files playback
USB
Decode
Media Codec
TS,mkv, mp4, avi, flv, f4v, ts, m2ts, mov, 3gp files
Audio Codec
WMA,MP3
Photo Codec
JPG, BMP, PNG, GIF
Product Dimension
175*120*40MM（L*W*H）
Packaged Size
240*178*59MM
Carton Size
500*320*380MM (20pcs/ctn)
Packing
Unit Weight
0.65 Kg with gift box
Carton Qty&Weight
20 pcs/Carton, 13.5 kgs
Accessories
Gift Box, Adapter, IR remote control, HDMI Cable, User Manual,Warranty card
Power Supply
AC 100V ～250V, 50/60Hz
Physicals
Power Consumptio
10W in operation
≦1 W Standby Power Mode
Temperature
Operation 0～+45℃; Storage -10~+60℃
Humidity
20~90%, non-condensed
-
