Productos relacionados con: GTMEDIA V7 S2X
-
Decodificador
-
Especificaciones Técnicas firmware original de fabrica
Highlight 1. Support DVB-S/S2/S2X, AVS+,VCM/ACM/multi-stream/T2MI 2.Support BISS auto roll, Full PowerVu, DRE &Biss key; 3.Support Unicable, DiSEqC1.0/1.1/1.2/USALS Motor fully support; 4.Support Full speed USB 3/4G dongle and USB wifi dongle, 5.Support Online Movie (Youtube,Youporn); 6.Technical support website : www.freesat.cn Main Chip Sets CPU frequency 550MHz Dual Core Flash Memory 64MB SPI Flash DDR2 Memory 512M RAM TS Demux Demultiplexer ISO/IEC 13818-1 Input Bit Rate Max 100Mbit/s Video Decode Video Decode HEVC main profile@level 4.1 and main10 profile@L4.1,High tier
MPEG-2 MP@ML
H.264 BP,MP&HP@L3/L4.1/L4.2
AVS Jizhun profile and broadcast profile
MPEG-4 SP profile, advanced simple profile@L5
VC1 SP@ML, MP@HL, AP@L0-3
H263 baseline profile
JPEG decoderPAL/NTSC Automatic PAL/NTSC conversion Aspect Ratio Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box Video Resolution 1080P, 1080I, 720P, 576P, 480P, 576I, 480I Audio Decode Audio Decode MPEG-1/2 Layer 1/2/3, MPEG-2/4 LC-AAC, MPEG-4 HE-AAC,
Dolby AC3/AC3+, DRA CH/5.1CHSound Mode LEFT/RIGHT/STEREO/MONO Sampling Frequency 32KHz,44.1KHz,48KHz Hardware specifications Panel display 4-digit LED display LED Indicator Power ON :Green; Standby :Red Button NC Wifi Support USB Wifi dongle (MTK7601/RT5370) IR Exit IR for 38KHz,Infra Remote control Rear Panel LNB IN (Frequency Range950MHz to 2150MHz DVB-S/S2/S2X) HD OUT (up to 1080P) RCA*3 (AV OUT) 2*USB 2.0 HOST Power (DC 12V/1.2A) DVB-S/S2 Tuner specificati-ons System standard ETS 302 307 Frequency Range 950~2150MHz for DVB-S/S2/S2X LNB Power and Polarization DiSEqC1.0/1.1/1.2/USALS Motor fully support, 13/18V DC @ 400mA MAX, 22KHz±0.4KHz(0.6V±0.2V)tone,Overload Protection Input Level Range -80dBm ~ -25dBm Symbol Rates DVB-S QPSK,DVB-S2 QPSK/8PSK/16APSK/32APSK,
DVB-S2X QPSK/8PSK/16APSK/32APSK/64APSKForward error correction rate 1/4,1/3,2/5,3/5,2/3,3/4,4/5,5/6,8/9,9/10 Carrier frequency acquisition range ±5MHz for symbol rates above 3 Msps and ±3MHz for the remaining symbol rates Symbol Rates 2 ~ 90MSPS(Code Rate 1/2) Code Rates 1/2,2/3,3/4,5/6,7/8 for DVB-S, 1/4,1/3,2/5,1/2,3/5,2/3,3/4,5/6
,8/9,9/10 for DVB-S2,
DVB-S2X Normal Frame and Short Frame FEC code ratesANT. Connector Connector:IEC TYPE F Input Impedance:75 Ω Sortware Features Standard Fully comply with DVB-S/S2/S2X (SCPC and MCPC receivable from C/Ku band satellite) Channels Number 5000+ channels TV and Radio programmable Favorites 16 different favorite groups selection OSD Language OSD Multi-language for options(English, Spanish, French, Russian, Portuguese, Polish, Indonesian, Arabic, Turkish, German, Italian, Persian, Thai) EPG Fully support to 7 days Electronic Program Guide(EPG) OSD Color 16-bit OSD with anti-flickering Channel Search Supports Automatic network search for newly added transponders Channel Edit Various channel editing function(favorite,move,lock,skip,
delete,rename,find,sort)Parental Ctrl Parental control for channels Easy Menu Plug and Play installation, with an easy to use Menu System SoftUpgrade Software upgrades through USB port upgrade. Channel Recording one channel, can view another channel under the same TP,Various channel editing function(favorite,move,lock,skip,delete,rename,find,sort) Subtitle support DVB EN300743 and EBU Teletext support DVB ETS300472 by VBI and OSD Time Set Time set by GMT offset automatic and manual,Summer Time support Timer 5 event timers,off/Once/Daily/Weekly Mode USB Decode USB 2.0 Support FAT/FAT32/NTFS big capacity hard disk PVR Option USB 2.0 for PVR,TIMESHIFT,media files playback Media Codec TS,mkv, mp4, avi, flv, f4v, ts, m2ts, mov, 3gp files Audio Codec WMA,MP3 Photo Codec JPG, BMP, PNG, GIF Packing Product Dimension 120*105*33mm （L*W*H） Packaged Size 205*175*52MM Carton Size 610*295*375MM---30pcs/ctn Unit Weight 0.46 Kg with gift box Carton Qty&Weight 40 pcs/Carton, 14.5 kgs optional Accessories Gift Box, Adapter, IR remote control, HDMI Cable, User Manual,Warranty card Physicals Power Supply AC 100-250V,50Hz/60Hz Power Consumption 8W in operation
≦1 W Standby Power ModeTemperature Operation 0～+45℃; Storage -10~+60℃ Humidity 20~90%, non-condensed -
Opiniones de clientes del GTMEDIA V7 S2X 2 item(s)
-
GTMEDIA V7 S2X muy buen producto
-
Enchufar y a funcionar, un gran decodificador. Me llego en fecha y ningún problema con la entrega.
Calidad -
Ningún problema todo correcto,. - recomiendo -
-
Uno de los mejores decodificadores satelites que he probado, recomiendo el GTMEDIA V7 S2X. El firmware del fabricante es muy potente.
Calidad
-
